Moulded Case Circuit Breaker
Model series:
STM2-100, STM2-160,STM2-250,STM2-400,STM2-630, STM2-800, STM2-1250
The Gross weight | 12pcs/21.5kg |
The dimension | 35.5*36.5*30.5(cm) |
M.O.Q | 20pcs (Samples Excepted) |
Payment term | T/T, L/C,D/P,O.A |
Delivery time | Usually 25 days (Negotiable for different order quantity) |
Standard: | IEC60947-2 |
Promote the products with our own brand (As one of our agents in your market)
Promote the products with neutral packing
Do OEM for you.
Application:
overload, short circuit, under-voltage protection
Characteristics:
STM2 series moulded case circuit breaker is one of the most advanced type breakers
in the world. They are suitable for short circuit and overload protection for circuit of
AC690V 50/60Hz, rated current from 12.5A to 800A. Its rated insulation voltage is
690V. It can be used as switch to make and break the circuit infrequently start,
stop and protect overload, short circuit and under voltage.
Moulded Case Circuit Breaker
Model series:
STM1-100, STM1-160,STM1-250,STM1-400,STM1-630
The Gross weight | 12pcs/21.5kg |
The dimension | 35.5*36.5*30.5(cm) |
M.O.Q | 20pcs (Samples Excepted) |
Payment term | T/T, L/C,D/P,O.A |
Delivery time | Usually 25 days (Negotiable for different order quantity) |
Standard: | IEC60947-2 |
Promote the products with our own brand (As one of our agents in your market)
Promote the products with neutral packing
Do OEM for you.
Application:
overload, short circuit, under-voltage protection
Characteristics:
STM1 series moulded case circuit breaker is one of the most advanced type breakers in the world. They are suitable for short circuit and overload protection for circuit of AC690V 50/60Hz, rated current from 12.5A to 630A. Its rated insulation voltage is 690V. It can be used as switch to make and break the circuit infrequently start, stop and protect overload, short circuit and under voltage.
Moulded Case Circuit Breaker
Model series:
STM2-100, STM2-160,STM2-250,STM2-400,STM2-630, STM2-800, STM2-1250
The Gross weight | 12pcs/21.5kg |
The dimension | 35.5*36.5*30.5(cm) |
M.O.Q | 20pcs (Samples Excepted) |
Payment term | T/T, L/C,D/P,O.A |
Delivery time | Usually 25 days (Negotiable for different order quantity) |
Standard: | IEC60947-2 |
Promote the products with our own brand (As one of our agents in your market)
Promote the products with neutral packing
Do OEM for you.
Application:
overload, short circuit, under-voltage protection
Characteristics:
STM2 series moulded case circuit breaker is one of the most advanced type breakers
in the world. They are suitable for short circuit and overload protection for circuit of
AC690V 50/60Hz, rated current from 12.5A to 1250A. Its rated insulation voltage is
690V. It can be used as switch to make and break the circuit infrequently start,
stop and protect overload, short circuit and under voltage.
Moulded Case Circuit Breaker
Model series:
STM3-100, STM3-160,STM3-250,STM3-400,STM3-630, STM3-800, STM3-1250
The Gross weight | 12pcs/21.5kg |
The dimension | 35.5*36.5*30.5(cm) |
M.O.Q | 20pcs (Samples Excepted) |
Payment term | T/T, L/C,D/P,O.A |
Delivery time | Usually 25 days (Negotiable for different order quantity) |
Standard: | IEC60947-2 |
Promote the products with our own brand (As one of our agents in your market)
Promote the products with neutral packing
Do OEM for you.
Application:
overload, short circuit, under-voltage protection
Characteristics:
STM3 series moulded case circuit breaker is one of the most advanced type breakers
in the world. They are suitable for short circuit and overload protection for circuit of
AC690V 50/60Hz, rated current from 12.5A to 1600A. Its rated insulation voltage is
690V. It can be used as switch to make and break the circuit infrequently start, stop
and protect overload, short circuit and under voltage.
Moulded Case Circuit Breaker
Model series:
STM4-100, STM4-160,STM4-250,STM4-400,STM4-630, STM4-800, STM4-1250
The Gross weight | 12pcs/21.5kg |
The dimension | 35.5*36.5*30.5(cm) |
M.O.Q | 20pcs (Samples Excepted) |
Payment term | T/T, L/C,D/P,O.A |
Delivery time | Usually 25 days (Negotiable for different order quantity) |
Standard: | IEC60947-2 |
Promote the products with our own brand (As one of our agents in your market)
Promote the products with neutral packing
Do OEM for you.
Application:
overload, short circuit, under-voltage protection
Characteristics:
STM4 series moulded case circuit breaker is one of the most advanced type breakers
in the world. They are suitable for short circuit and overload protection for circuit of
AC690V 50/60Hz, rated current from 12.5A to 1250A. Its rated insulation voltage is
690V. It can be used as switch to make and break the circuit infrequently start,
stop and protect overload, short circuit and under voltage.
ATS1 Series Automatic Transfer Switch
Model | MCCB Applied | No of pole and short circuit breaking capacity | Rated current | L | M |
ATS1-63 | MGM1-63 | 3 Pole(L,M), 4 Pole | 10,16,20,25, 32,40,50,63 | 25 | 50 |
ATS1-100 | MGM1-100 | 3 Pole (L,M,H), 4 Pole | 10,16,20,25, 32,40,50,63, 80,100 | 35 | 50 |
ATS1-160 | MGM1-160 | 3 Pole (L,M,H), 4 Pole | 100,125,140.160 | 35 | 50 |
ATS1-225 | MGM1-225 | 3 Pole (L,M,H), 4 Pole | 100,125,140,160, 180,200,225 | 35 | 50 |
ATS1-400 | MGM1-400 | 3 Pole (L,M,H), 4 Pole | 225,250,315,350,400 | 50 | 65 |
ATS1-630 | MGM1-630 | 3 Pole (L,M,H), 4 Pole | 400,500,630 | 50 | 65 |
ATS1-800 | MGM1-800 | 3 Pole (L,M,H), 4 Pole | 630,700,800 | 50 | 65 |
ATS1 series automatic transfer switch (ATS) is suitable for the transfer between two
power sources,common source (power supply I) and standby power supply
(power supply II ),whose rated voltage is below 50Hz,400v (AC) when one power
supply malfunctions to assure the safe, and stable power supply. The setting mainly
used for hospital, shopping center, bank, and chemical industry ,metallurgy, high
building,military facilities etc important situation where power breaking can't be
allowed. Standard: IEC60947-6-1,GB14048.11-2002,etc.
ATS2 Series Automatic Transfer Switch
Model | MCCB Applied | No of pole and short circuit breaking capacity | Rated current | L | M |
ATS2-63 | MGM1-63 | 3 Pole(L,M),4 Pole | 10,16,20,25, 32,40,50,63 | 25 | 50 |
ATS2-100 | MGM1-100 | 3 Pole (L,M,H),4 Pole | 10,16,20,25, 32,40,50,63, 80,100 | 35 | 50 |
ATS2-160 | MGM1-160 | 3 Pole (L,M,H),4 Pole | 100,125,140.160 | 35 | 50 |
ATS2-225 | MGM1-225 | 3 Pole (L,M,H),4 Pole | 100,125,140,160, 180,200,225 | 35 | 50 |
ATS2-400 | MGM1-400 | 3 Pole (L,M,H),4 Pole | 225,250,315,350,400 | 50 | 65 |
ATS2-630 | MGM1-630 | 3 Pole (L,M,H),4 Pole | 400,500,630 | 50 | 65 |
ATS2-800 | MGM1-800 | 3 Pole (L,M,H),4 Pole | 630,700,800 | 50 | 65 |
ATS2 series automatic transfer switch (ATS) is suitable for the transfer between two
power sources,common source (power supply I) and standby power supply (power
supply II ),whose rated voltage is below 50Hz,400v (AC) when one power supply
malfunctions to assure the safe, and stable power supply. The setting mainly used
for hospital, shopping center, bank, and chemical industry ,metallurgy, high building,
military facilities etc important situation where power breaking can't be allowed.
Standard: IEC60947-6-1,GB14048.11-2002,etc.
ATS3 Series Automatic Transfer Switch
Type | ATS3-125 | ||||||||||||
monolithic type | split type | ||||||||||||
Rated current | 16, 25, 32 | 40, 63,125 | 16, 25, 32 | 40, 63,125 | |||||||||
Operating current | 3.5 | ||||||||||||
Rated limit short circuit current | 35 | ||||||||||||
Life time | Mechanism | 8000 | |||||||||||
Eletric | 3000 | ||||||||||||
Pole | 2P | 3P | 4P | 2P | 3P | 4P | 2P | 3P | 4P | 2P | 3P | 4P | |
Weight | 4.2 | 4.7 | 5.2 | 5 | 5.5 | 6.5 | 3.2 | 3.7 | 4.2 | 4 | 4.5 | 5.5 | |
operation cycle(s/t) | 15 |
Type | ATS3-400 | ||||||||||
Rated current(A) | 160 | 200 | 250 | 315 | 400 | ||||||
Operating current(A) | 7 | ||||||||||
Rated limit short circuit current(A) | 35 | ||||||||||
Life time | Mechamism | 6000 | |||||||||
Electric | 2000 | ||||||||||
Pole | 3P | 4P | 3P | 4P | 3P | 4P | 3P | 4P | 3P | 4P | |
Weight | 16 | 18 | 17 | 19 | 18 | 20 | 18.5 | 20.5 | 19 | 21 | |
Operation cycle(s/t) | 10 |
ATS3 series automatic transfer switch is applicable for distribution net work of AC50Hz,
rated voltage of 400V, it has 3P and 4P.
ATS3 series automatic transfer switch is used in hospitals,hotels,market ,post and
communication, fire high building, industrial assembly line by widely.
Standard: GB/T14048.6.
ATS3 Series Automatic Transfer Switch
Type | ATS3-1600 | ATS3-3200 | |||||||||||||||
Rated current(A) | 630 | 800 | 1000 | 1250 | 1600 | 2000 | 2500 | 3200 | |||||||||
Operating current(A) | 16 | ||||||||||||||||
Rated working voltage(Ue) | AC 400V | ||||||||||||||||
Rated limit short circuit current(A) | 50 | 65 | |||||||||||||||
Life time | Mechanism | 3000 | |||||||||||||||
Electric | 1000 | ||||||||||||||||
Pole | 3P | 4P | 3P | 4P | 3P | 4P | 3P | 4P | 3P | 4P | 3P | 4P | 3P | 4P | 3P | 4P | |
Weight | 37 | 42.5 | 39 | 46 | 41 | 48 | 48 | 57 | 56 | 67 | 64 | 85.5 | 79.5 | 104 | 98 | 125 | |
Operation cycle(s/t) | 15 | 20 | 25 | 25 | 25 | 25 | 25 | 25 |
ATS3 series automatic transfer switch is applicable for distribution net work of AC50Hz,
rated voltage of 400V, it has 3P and 4P.
ATS3 series automatic transfer switch is used in hospitals,hotels,market ,post and
communication, fire high building, industrial assembly line by widely.
Standard: GB/T14048.6.
ATS4 Series Automatic Transfer Switch
Promissory heat current(A) | 32 | 40 | 63 | 80 | 100 | 125 | 160 | 250 | 400 | 630 | 1000 | 1250 | 1600 | 2000 | 2500 | 3200 | |||
Rated insulation voltage | 750V | 1000V | |||||||||||||||||
The strength of insulation power | 3KV | 5KV | |||||||||||||||||
Rated impulsion endurance voltage | 8KV | 12KV | |||||||||||||||||
Rated working current(A) | AC-31 | 32 | 40 | 63 | 80 | 100 | 125 | 160 | 250 | 400 | 630 | 1000 | 1250 | 1600 | 2000 | 2500 | 3200 | ||
AC-35 | 32 | 40 | 63 | 80 | 100 | 125 | 160 | 250 | 400 | 630 | 1000 | 1000 | 1600 | 2000 | 200 | 2500 | |||
AC-33 | 32 | 40 | 63 | 80 | 100 | 125 | 160 | 250 | 400 | 630 | 800 | 800 | 1000 | 1250 | 1250 | 1600 | |||
Rated short time endurance current | 7KV | 9KV | 13KV | 26KV | |||||||||||||||
Rated limited short circuit current | 70KV | 100KV | 120KV | ||||||||||||||||
Operating torque(N.m) | 12 | 19 | 26 | 39 | 50 | 80 | |||||||||||||
Motor comsumpsion | Starting | 300 | 235 | 355 | 440 | 600 | |||||||||||||
Normal | 55 | 62 | 74 | 98 | 120 | ||||||||||||||
Transfer time(s) | 0.45 | 0.6 | 1.2 | 1.5 | |||||||||||||||
Mechnical life (times) | 10000 | 5500 | 4000 | 3000 | |||||||||||||||
Weight(Kg) | 3poles | 7.2 | 8 | 8.2 | 14 | 15 | 30 | 34 | 42 | 85 | 76 | 120 | |||||||
4poles | 7.5 8.5 | 8.5 | 9 | 16 | 17 | 36 | 40 | 49 | 95 | 98 | 135 |
Main Technical Parameter
According to standard: IEC60947-6-1 GB14048.11
Rated working voltage(Ue): AC400V
Rated connecting capacity (A Rms):10le
Rated breaking capacity (A Rms):8le
STLS1 Series Load Switch
Application:
STLS1 series load switch is mainly applied to power distribution circuit with rated
AC 50 Hz, rated voltage up to 690V and rated working current up to 3200A for
making and breaking or isolating the circuit.
Standard:IEC60947-3, GB 14048.3 etc.
Air Circuit Breaker
The Gross weight |
|
The dimension |
|
M.O.Q | 1pcs |
Payment term | T/T, L/C,D/P,O.A |
Delivery time | Usually 25 days (Negotiable for different order quantity) |
Promote the products with our own brand (As one of our agents in your market)
Promote the products with neutral packing
Do OEM for you.
Function:
IEC60947-1, IEC60947-4-1, IEC60947-2
High short-time current rating:
6300A 100kA 1sec
4000A 100kA 1sec
2000A 100kA 1sec
100% rated current operation
3 poles and 4 poles available
fixed and drawer installation type available
Technical parameters:
Rated Current In (A): 400~6300
Rated Current of N-pole :100%In
Frame rated current Inm (A) :63~800
Rated Insulation Voltage Ui (V):1000
Ultimate breaking capacity Icu AC 400V (kA) :80, 100, 120
Rated service breaking capacity Ics AC 400V (kA) :50,80,100
Rated short time withstand current 1S Icw(kA):50, 65, 100
Rated service voltage Ue(V) :AC690
Making time (ms) :30
Breaking time (ms) :60
Poles: 3, 4
Electrical life (times): 500
Mechanical life with maintenance (times): 10000, 8000
